SUNNYSKY X2216 III V3 Brushless Motor - KV880 KV950 KV1100 KV1250 KV1400 KV2600
13 orders (reference)
Description
SUNNYSKY X2216 III V3 Brushless Motor - KV880 KV950 KV1100 KV1250 KV1400 KV2600 ============================================================ Motor Model / KV X2216-III/ KV880 X2216-III/ KV950 X2216-III/ KV1100 X2216-III/ KV1250 X2216-III/ KV1400 Stator/Rotor Poles 12N14P 12N14P 12N14P 12N14P 12N14P Internal resistance 73.6mΩ 32.2mΩ Motor size Long-Sleeve:φ27.7*50.0mm Short-Sleeve:φ27.7*36.5mm Long-Sleeve:φ27.7*50.0mm Short-Sleeve:φ27.7*36.5mm Long-Sleeve:φ27.7*50.0mm Short-Sleeve:φ27.7*36.5mm Long-Sleeve:φ27.7*50.0mm Short-Sleeve:φ27.7*36.5mm Long-Sleeve:φ27.7*50.0mm Short-Sleeve:φ27.7*36.5mm Shaft diameter 3.175mm 3.175mm 3.175mm 3.175mm 3.175mm 20AWG 100mm 20AWG 100mm 20AWG 100mm 20AWG 100mm 20AWG 100mm Motor weight(wire included) Motor weight(wire excluded) No data No data No data No data No data Rated operational voltage No-load current 0.5A/10V 0.7A/10V 0.8A/10V 1A/10V 1.2A/10V Maximum continuous power Maximum continuous current 32A/30S 32A/30S 34A/30S 40A/30s 50A/30s ESC recommended use 30-40A 40-50A Propeller size recommended use APC9047/9045/APC11*4.7/1047 APC 9047/APC 9045/APC11*4.7/APC 1047 APC9047/APC9045/APC8060/APC1047 APC9047/APC9045/APC8060/APC1047 APC9047/APC9045/APC8060 AVAILABLE OPTIONS ShortShaft KV880 ShortShaft KV950 ShortShaft KV1100 ShortShaft KV1250 ShortShaft KV1400 ShortShaft KV2600 LongShaft KV880 LongShaft KV950 LongShaft KV1100 LongShaft KV1250 LongShaft KV1400 LongShaft KV2600 PRODUCT INFORMATION Brand: SunnySky Category: Brushless Motor Wholesale Price: US $24.49 ————————————————————————————————————————
Specifications
| Attribute | Value |
|---|---|
| High-concerned chemical | None |
| Is Electric | No Battery |
| Is it battery/power supply | N |
| Is it charger/adapter | N |
| Is Batteries Included | No |
| Model Number | X2216 III |
| For Vehicle Type | Helicopters |
| Tool Supplies | Battery |
| Four-wheel Drive Attributes | Battery |
| Remote Control Peripherals/Devices | Battery |
| Upgrade Parts/Accessories | Lithium Battery |
| RC Parts & Accs | Batteries - LiPo |
| Material | Composite Material |
| Origin | Mainland China |
| Recommend Age | 14+y |
| Use | Vehicles & Remote Control Toys |
Product Details
Motor Model / KV | X2216-III/ KV880 | X2216-III/ KV950 | X2216-III/ KV1100 | X2216-III/ KV1250 | X2216-III/ KV1400 |
Stator/Rotor Poles | 12N14P | 12N14P | 12N14P | 12N14P | 12N14P |
Internal resistance | 89mΩ | 73.6mΩ | 54mΩ | 45mΩ | 32.2mΩ |
Motor size | Long-Sleeve:φ27.7*50.0mm | Long-Sleeve:φ27.7*50.0mm | Long-Sleeve:φ27.7*50.0mm | Long-Sleeve:φ27.7*50.0mm | Long-Sleeve:φ27.7*50.0mm |
Shaft diameter | 3.175mm | 3.175mm | 3.175mm | 3.175mm | 3.175mm |
AWG | 20AWG 100mm | 20AWG 100mm | 20AWG 100mm | 20AWG 100mm | 20AWG 100mm |
Motor weight(wire included) | 67.5g | 69g | 69g | 69g | 71g |
Motor weight(wire excluded) | No data | No data | No data | No data | No data |
Rated operational voltage | 3-4S | 3-4S | 3-4S | 3-4S | 3-4S |
No-load current | 0.5A/10V | 0.7A/10V | 0.8A/10V | 1A/10V | 1.2A/10V |
Maximum continuous power | 450W | 450W | 480W | 600W | 740W |
Maximum continuous current | 32A/30S | 32A/30S | 34A/30S | 40A/30s | 50A/30s |
ESC recommended use | 50A | 50A | 30-40A | 40A | 40-50A |
Propeller size recommended use | APC9047/9045/APC11*4.7/1047 | APC 9047/APC 9045/APC11*4.7/APC 1047 | APC9047/APC9045/APC8060/APC1047 | APC9047/APC9045/APC8060/APC1047 | APC9047/APC9045/APC8060 |
