Sunnysky X2212 980KV/1250KV/KV1400/2450KV 2-4S Brushless Motor (Short shaft) For RC Multi-rotor Aircraft Aerobatic Quadcopter
7 orders (reference)
Description
Sunnysky X2212 980KV/1250KV/KV1400/2450KV 2-4S Brushless Motor (Short shaft) For RC Multi-rotor Aircraft Aerobatic Quadcopter ============================================================ Sunnysky X2212 980KV/1250KV/KV1400/2450KV 2-4S Brushless Motor (Short shaft) Sunnysky X2212 KV980 Motor: Stator Diameter: 22mm; Stator Thickness: 12mm; No. Of Stator Slots: 12; No. Of Rotor Poles: 14; Motor KV:980; No-load Current (A/10V): 0.6A; Motor Resistance: 92mΩ； Max Continuous Current: 26A/30S; Max Continuous Power: 385W; Weight: 57g; Rotor Diameter: 27.5mm; Body Length: 30mm; Max Lipo Cell: 3-4S; ESC: 20-30A; Recommend Pro(Inch): APC8038/APC1047/APC1038/APC9047/APC9045; Suitable For Multi-rotor Single Shaft Weight: 400g 3-4S 1038\1047; Suitable For Multi-rotor Single Shaft Weight: 500g(4S 8038\8043\8045\9047); Trainer (Suitable For Trainer Weight): 750g 3S 1047; Suitable For 3D Aircraft Weight: 550g(3S 1047); Sunnysky X2212 KV1250 Motor: Stator Diameter: 22mm; Stator Thickness: 12mm; No. Of Stator Slots: 12; No. Of Rotor Poles: 14; Motor KV:1250; No-load Current (A/10V): 0.8A; Motor Resistance: 54mΩ； Max Continuous Current: 35A/30S; Max Continuous Power: 518W; Weight: 59g; Rotor Diameter: 27.5mm; Body Length: 30mm; Max Lipo Cell: 3-4S; ESC: 30-40A; Recommend Pro(Inch): APC9047/APC9060/APC8060/APC7060; Aerobatic(Suitable For Aerobatic Weight): 750g (3S 9047\9060\9045\8060); Suitable For 3D Aircraft Weight: 550g(3S 9047\9045); Sunnysky X2212 KV1400 Motor: Stator Diameter: 22mm; Stator Thickness: 12mm; No. Of Stator Slots: 12; No. Of Rotor Poles: 14; Motor KV:1400; No-load Current (A/10V): 1A; Motor Resistance: 43mΩ； Max Continuous Current: 35A/30S; Max Continuous Power: 560W; Weight: 57g; Rotor Diameter: 27.5mm; Body Length: 30mm; Max Lipo Cell: 3-4S; ESC: 30-40A; Recommend Pro(Inch): APC9047/APC9045/APC8038/APC7060/APC8060; Aerobatic(Suitable For Aerobatic Weight): 750g (3S 9047\9045\8060) (4S 7060); Sunnysky X2212 KV2450 Motor: Stator Diameter: 22mm; Stator Thickness: 12mm; No. Of Stator Slots: 12; No. Of Rotor Poles: 10; Motor KV:2450; No-load Current (A/10V): 1.6A/10V; Motor Resistance: 32mΩ； Max Continuous Current: 40A/30S; Max Continuous Power: 450W; Weight: 57g; Rotor Diameter: 27.5mm; Shaft Diameter: 3.175mm; Body Length: 30mm; Max Lipo Cell: 2-3S; ESC: 40A; Recommend Pro(Inch): APC6040; Weight For Tail-pushed Aerobatics: 550g(3S 6040); TECHNICAL SPECIFICATIONS • Weight: 57g; • Weight: 59g; AVAILABLE OPTIONS 1pcs X2212 KV980 1pcs X2212 KV1250 1pcs X2212 KV1400 1pcs X2212 KV2450 2pcs X2212 KV980 2pcs X2212 KV980 2pcs X2212 KV1250 2pcs X2212 KV2450 4pcs X2212 KV1250 4pcs X2212 KV1400 4pcs X2212 KV2450 4pcs X2212 KV980 PRODUCT INFORMATION Brand: SunnySky Category: Brushless Motor Wholesale Price: US $19.01 ————————————————————————————————————————
Specifications
| Attribute | Value |
|---|---|
| High-concerned chemical | None |
| Is Electric | No Battery |
| Is it battery/power supply | N |
| Is it charger/adapter | N |
| Is Batteries Included | No |
| Technical parameters | value 2 |
| Material | Metal |
| Brand Name | NoEnName_Null |
| Origin | Mainland China |
| Recommend Age | 14+y |
| Use | Vehicles & Remote Control Toys |
Product Details
Sunnysky X2212 980KV/1250KV/KV1400/2450KV 2-4S Brushless Motor (Short shaft)
Sunnysky X2212 KV980 Motor:
Stator Diameter: 22mm;
Stator Thickness: 12mm;
No. Of Stator Slots: 12;
No. Of Rotor Poles: 14;
Motor KV:980;
No-load Current (A/10V): 0.6A;
Motor Resistance: 92mΩ；
Max Continuous Current: 26A/30S;
Max Continuous Power: 385W;
Weight: 57g;
Rotor Diameter: 27.5mm;
Body Length: 30mm;
Max Lipo Cell: 3-4S;
ESC: 20-30A;
Recommend Pro(Inch): APC8038/APC1047/APC1038/APC9047/APC9045;
Suitable For Multi-rotor Single Shaft Weight: 400g 3-4S 1038\1047;
Suitable For Multi-rotor Single Shaft Weight: 500g(4S 8038\8043\8045\9047);
Trainer (Suitable For Trainer Weight): 750g 3S 1047;
Suitable For 3D Aircraft Weight: 550g(3S 1047);
Sunnysky X2212 KV1250 Motor:
Stator Diameter: 22mm;
Stator Thickness: 12mm;
No. Of Stator Slots: 12;
No. Of Rotor Poles: 14;
Motor KV:1250;
No-load Current (A/10V): 0.8A;
Motor Resistance: 54mΩ；
Max Continuous Current: 35A/30S;
Max Continuous Power: 518W;
Weight: 59g;
Rotor Diameter: 27.5mm;
Body Length: 30mm;
Max Lipo Cell: 3-4S;
ESC: 30-40A;
Recommend Pro(Inch): APC9047/APC9060/APC8060/APC7060;
Aerobatic(Suitable For Aerobatic Weight): 750g (3S 9047\9060\9045\8060);
Suitable For 3D Aircraft Weight: 550g(3S 9047\9045);
Sunnysky X2212 KV1400 Motor:
Stator Diameter: 22mm;
Stator Thickness: 12mm;
No. Of Stator Slots: 12;
No. Of Rotor Poles: 14;
Motor KV:1400;
No-load Current (A/10V): 1A;
Motor Resistance: 43mΩ；
Max Continuous Current: 35A/30S;
Max Continuous Power: 560W;
Weight: 57g;
Rotor Diameter: 27.5mm;
Body Length: 30mm;
Max Lipo Cell: 3-4S;
ESC: 30-40A;
Recommend Pro(Inch): APC9047/APC9045/APC8038/APC7060/APC8060;
Aerobatic(Suitable For Aerobatic Weight): 750g (3S 9047\9045\8060) (4S 7060);
Sunnysky X2212 KV2450 Motor:
Stator Diameter: 22mm;
Stator Thickness: 12mm;
No. Of Stator Slots: 12;
No. Of Rotor Poles: 10;
Motor KV:2450;
No-load Current (A/10V): 1.6A/10V;
Motor Resistance: 32mΩ；
Max Continuous Current: 40A/30S;
Max Continuous Power: 450W;
Weight: 57g;
Rotor Diameter: 27.5mm;
Shaft Diameter: 3.175mm;
Body Length: 30mm;
Max Lipo Cell: 2-3S;
ESC: 40A;
Recommend Pro(Inch): APC6040;
Weight For Tail-pushed Aerobatics: 550g(3S 6040);
