Description

Foxeer M10Q-120 V2 / M10Q-180 V2 / M10Q-250 V2 M10 Dual Protocol GPS FPV Built-in QMC5883 Compass For FPV RC Airplane Drone ============================================================ M10Q 180 V2 GPS Chip M10(10th Generation Chip) Frequency GPS L1，GLONASS L1，BDS B1，GALILEO， ESBAS L1，QZSS L1 Input Voltage 5V Antenna Ceramic Antenna Channel 72 Battery Bilid-in Compass IST8310 Compass Orientation Plug facing direction of flight and obviously antenna up, BF: CW 270° Flip Baud Rate 115200bps Protocol Dual NMEA/UBLOX Output Frequency 1Hz-10Hz,10Hz default Speed Accuracy 0.05m/s Horizontal Positioning Accuracy 2D ACC1.5m(outdoor) Receiver Sensitivity Trace -166dBm; Capture -160dBm Dynamic Characteristics Height 50000m; Speed 500m/s; Acceleration 4G Operating Temperature -40C-+85C Storage temperature -40C-+105C Weight 7.5g Size 18*18*8mm M10Q 120 V2 GPS Chip M10(10th Generation Chip) Frequency GPS L1，GLONASS L1，BDS B1，GALILEO， ESBAS L1，QZSS L1 Input Voltage 5V Antenna Ceramic Antenna Channel 72 Battery Bilid-in Compass IST8310 Compass Orientation Plug facing direction of flight and obviously antenna up, BF: CW 90° Flip Baud Rate 115200bps Protocol Dual NMEA/UBLOX Output Frequency 1Hz-10Hz,10Hz default Speed Accuracy 0.05m/s Horizontal Positioning Accuracy 2D ACC1.5m(outdoor) Receiver Sensitivity Trace -166dBm; Capture -160dBm Dynamic Characteristics Height 50000m; Speed 500m/s; Acceleration 4G Operating Temperature -40C-+85C Storage temperature -40C-+105C Weight 2.7g Size 12.5*17*5mm M10Q 250 V2 GPS Chip M10(10th Generation Chip) Frequency GPS L1，GLONASS L1，BDS B1，GALILEO， ESBAS L1，QZSS L1 Input Voltage 5V Antenna Ceramic Antenna Channel 72 Battery Bilid-in Compass IST8310 Compass Orientation Plug facing direction of flight and obviously antenna up, BF: CW 180 flip Baud Rate 115200bps Protocol Dual NMEA/UBLOX Output Frequency 1Hz-10Hz,10Hz default Speed Accuracy 0.05m/s Horizontal Positioning Accuracy 2D ACC1.5m(outdoor) Receiver Sensitivity Trace -166dBm; Capture -160dBm Dynamic Characteristics Height 50000m; Speed 500m/s; Acceleration 4G Operating Temperature -40C-+85C Storage temperature -40C-+105C Weight 12g Size 25*25*8mm AVAILABLE OPTIONS Q120 V2 Q180 V2 Q250 V2 PRODUCT INFORMATION Brand: Foxeer Category: FPV Drone Wholesale Price: US $42.39 ————————————————————————————————————————
