Happymodel 2.4G T Omnidirectional FPV Antenna 40MM 90MM IPEX U.FL For ELRS EP1 EP2 Receiver TBS Tracer RC FPV D
Description
Happymodel 2.4G T Omnidirectional FPV Antenna 40MM 90MM IPEX U.FL For ELRS EP1 EP2 Receiver TBS Tracer RC FPV D ============================================================ Frequency (MHz) 2400.0 Efficiency (dBi) -0.89 Gain (dBi) 2.23 Efficiency (%) 81.46 Directivity (dB) 5.12 Peak Gain Position (Theta) 180.00 Peak Gain Position (Phi) 330.00 Efficiency ThetaPol (%) 20.90 Efficiency PhiPol (%) 60.56 Upper Hem. Efficiency (%) 39.93 Lower Hem. Efficiency (%) 41.54 Connector IPEX/IPX/U.FL Antenna width 52mm Antenna length 40mm/90mm(optional) AVAILABLE OPTIONS 40MM 90MM PRODUCT INFORMATION Brand: HappyModel Category: FPV Drone Wholesale Price: US $0.99 ————————————————————————————————————————
Product Details
Frequency (MHz) 2400.0
Efficiency (dBi) -0.89
Gain (dBi) 2.23
Efficiency (%) 81.46
Directivity (dB) 5.12
Peak Gain Position (Theta) 180.00
Peak Gain Position (Phi) 330.00
Efficiency ThetaPol (%) 20.90
Efficiency PhiPol (%) 60.56
Upper Hem. Efficiency (%) 39.93
Lower Hem. Efficiency (%) 41.54
Connector IPEX/IPX/U.FL
Antenna width 52mm
Antenna length 40mm/90mm(optional)
